BEYMA 18LX60V2
BEYMA 18LX60V2
Low Frequency Chassis
• Durchmesser: 18"
• Belastbarkeit: 700 W AES
• Empfindlichkeit: 98 dB
• Impedanz: 8 Ω
• Frequenzbereich: 25-1000 Hz
• Magnettyp: Ferrite
• Fs: 35 Hz | Qts: 0.48 | Vas: 236 l
| 1.00 Hersteller: BEYMA |
| 1.01 Produktkategorie: Low Frequency |
| 1.02 Produktserie: LX |
| 2.00 Nenndurchmesser (Zoll): 18 |
| 2.01 Schwingspule (Zoll): 4 |
| 2.02 Einbautiefe (mm): 193 |
| 2.03 Gewicht (kg): 11.2 |
| 2.04 Magnettyp: Ferrite |
| 3.00 Impedanz (Ohm): 8 |
| 3.01 Re (Ohm): 5.1 |
| 3.02 Le (mH): 2.1 |
| 4.00 Belastbarkeit (W): 700 |
| 4.01 Empfindlichkeit (dB): 98 |
| 4.02 Frequenzbereich: 25-1000 |
| 5.00 Fs (Hz): 35 |
| 5.01 Qms: 15.7 |
| 5.02 Qes: 0.5 |
| 5.03 Qts: 0.48 |
| 5.04 Vas (l): 236 |
| 5.05 Xmax (mm): 8 |
| 5.06 Vd (cm³): 1056 |
| 5.07 BL (Tm): 21.8 |
| 5.08 Mms (kg): 0.215 |
| 5.09 Sd (m²): 0.132 |
